Kullanım Klavuzu: AT-48DSP manual-251204.pdf

PC Tuning Software link ⇒ AT-48DSP_25112025.zip

• Voltage Range 5.3V-16.5V
• Input Channel
• 4 channels high level
• 2 channels low level
• Optical fiber input
• Bluetooth input
• Output Channel 8-channel low-level output
• Low Level Output Voltage ≥3V
• High Level
• Input Impedence
• ≤33Ω（Automatic selection
• of input impedance）
• RCA Input Impedence ≥10K
• Low Level
• Output Impedence <50Ω
• RCA Input S/N ≥105dBA
• High Level Input S/N ≥100dBA
• RCA Input T.H.D 0.01%
• High Level Input T.H.D 0.02%
• REM OUT Output Current >100mA
• RCA Input Sensitivity 1.4V-2.8V
• High level input Sensitivity 5V-10V, 10V-20V
• EQ(variable)
• Dimensions(W x H x D) 156.5 x 87 x 26.5mm
